injection molding mold

An injection molding  mold having a pair of fixed and moveable molding plates, a plurality of sidewalls moved by one or more hydraulic cylinder assemblies.

The plurality of sidewalls moved by one or more hydraulic cylinder assemblies arranged between the fixed and movable molding plates.

A plurality of sidewalls moved between the fixed and movable formers by inclined guide pins or guide blocks.

A core component with a sloping surface and fixed to the movable forming plate.

A core part with an inclined surface and fixed to a movable forming plate within the sidewalls, with a slider core part that moves in engagement with the core part.

engagement with the core member. The individual sidewalls, as well as the sidewalls and the slider core member, are connected by a connecting device.

The sidewalls, sides, and slider core are connected by a connecting mechanism including a connecting plate and a connecting plate to allow the sidewalls and slider core to be movably engaged with the core.

The connecting plate so that the sidewall and slider core member are moved simultaneously by at least one hydraulic cylinder assembly.
